Synology FS6400 24 Bay NAS Flash Station | USED

Synology FS6400 24 Bay NAS Flash Station | USED

Part Number: FS6400

Condition: Used

#### SYNOLOGY FS6400 24 Bay Nas Flash Station, 2 X Intel Xeon 8-core Silver 4110 2.1ghz, 32gb (16 Gb X 2) Ddr4 Ecc Rdimm, Pci-e Expansion 2 X Gen3 X8 Slots (x8 Link), 2 X 800w Power Supply

**General Information :**

Manufacturer : SYNOLOGY

Manufacturer Part Number : FS6400

Manufacturer Website Address : HTTPS://WWW.SYNOLOGY.COM/

Product Name : SYNOLOGY FS6400 24 Bay Nas Flash Station

**Processor & Chipset :**

Processors Installed : 2 X Intel Xeon 8-core Silver 4110 2.1ghz

Number Of Cores : Octa-core

Max Supported Qty : 2

**Memory :**

System Memory : 32 Gb Ddr4 Ecc Rdimm

Memory Module Pre-installed : 16gb X 2

Total Memory Slots : 16

Memory Expandable Up To : 512 Gb (32 Gb X 16)

**Storage & Storage Controller :**

Drive Bays : 24 Bays

Maximum Drive Bays With Expansion Unit : 48 (rx1217sas X 2) / 72 (fx2421 X 2)

compatible Drive Type :

2.5 Sas Hdd

2.5 Sas Ssd

2.5 Sata Ssd

Hot Swappable : Yes

Storage Controller Type : Raid

Raid Level : Raid 0, Raid 1, Raid 5, Raid 6, Raid 10, Jbod, Raid F1

**Display & Graphics Controllers :**

graphics Controller

**Network & Communication :**

Data Link Protocol : 10mb Lan, 100mb Lan, Gige, 10 Gige

Network / Transport Protocol : Pptp, L2tp, Iscsi, Smtp, Ftp, Smb, Https

Remote Management Protocol : Snmp, Telnet, Https, Ssh, Smtp, Ldap

Network Services Compatibility : Microsoft Active Directory (ad), Network
File System (nfs), Ftp, Server Message Block (smb), Apple File Protocol (afp), Https, Web-based Distributed Authoring And Versioning (webdav), Calendaring Extensions To Webdav (caldav)

Features : Firewall Protection, Vpn Support, Ldap Support, Wake On Lan (wol), Antivirus Analysis, High Availability, Anti-malware Protection, Access Control List (acl) Support, E-mail Server, Reset Button, Bandwidth Control, Surveillance Station, Vpn Server, Failover Protection, Openstack Compatible, B-tree File System (btrfs), File Station, Ext4 File System, Iscsi Lun Clone/snapshot, Windows Odx, Mailplus Server

**Security Dvr :**

Ip Cameras Supported : 128

Compression Format : Mjpeg, H.264, H.265

Image Resolution : 1280x720, 1920x1080, 2048x1536, 2591x1944, 3840x2160

**Expansions & Connectivity :**

expansion Bays Total (free) :

24 (total) / 24 (free) X Hot-swap - 2.5

Expansion Slots Total (free) :

2 X Pci Express 3.0 X8

16 (total) / 14 (free) X Dimm 288-pin

Interfaces & Ports :

2 X Ethernet 1000base-t - Rj-45

2 X Usb 3.0 - Type A

1 X Serial - Db-9

2 X Ethernet 10gb - Rj-45

**Power Device :**

Power Device : Internal Power Supply

Installed Qty : 2

Max Supported Qty : 2

Power Redundancy : Yes

Voltage Required : Ac 120/230 V ( 50/60 Hz )

Power Consumption Operational : 288.49 Watt

Power Provided : 800 Watt

**dimensions & Weight :**

Width : 19 In

Depth : 28.5 In

Height : 3.5 In

Weight : 38.05 Lbs
