(NEW) Cisco Nexus 9000 Series Switches - N9K-X9400-16W

Overview

The Cisco N9K-X9400-16W is a high-performance modular switch designed for scalable and efficient data center environments. This switch features 16 ports of 100 Gigabit Ethernet and is built to support large-scale enterprise and service provider networks. It leverages advanced hardware and software capabilities, providing optimal performance, flexibility, and robust management features suitable for demanding applications such as cloud computing and big data analytics.

Specs

Port Configuration:

• Ports:
  • 16 x 100-Gigabit Ethernet ports (QSFP28)
• Modular Design: Compatible with Cisco Nexus 9400 series chassis for modular expansion.

Performance:

• Switching Capacity: Up to 6.4 Tbps (Terabits per second)
• Forwarding Rate: Up to 4.76 Bpps (Billion packets per second)
• Latency: Low latency optimized for high-speed data transfer.

Layer 2 and Layer 3 Features:

• Layer 2:

  • VLAN support, Spanning Tree Protocol (STP), and Virtual Port Channel (vPC) for redundancy and load balancing.

• Layer 3:

  • Full support for IPv4 and IPv6 routing protocols, including OSPF, BGP, and EIGRP.
  • VXLAN support for overlay networking, enhancing scalability and segmentation.

Automation and Programmability:

• Operating System: Cisco NX-OS.
• Automation Features: Model-driven programmability, REST APIs, and support for Cisco's automation tools for efficient management.
• Management: Compatible with Cisco Data Center Network Manager (DCNM) for centralized control and monitoring.

Security Features:

• Access Control Lists (ACLs): Advanced security features for traffic filtering.
• Microsegmentation: Enables granular security policies for applications, enhancing network security.
• Role-Based Access Control (RBAC): Provides controlled access based on user roles to secure network resources.
